MATERIAL HANDLING SEATS
F150/MN50
|
Mechanical suspension |
●
|
Weight adjustment |
Manual up to 150kgs. |
Suspension stroke |
50mm |
Height adjustment |
N/A |
Turn Table |
▲
|
Slide travel |
210mm |
Lumbar adjustment |
N/A |
Hip restraints |
▲
|
Adjustable / Foldable armrests |
▲
|
Headrest |
N/A |
Backrest adjustment |
N/A |
Vinyl trim (Vacuum type) |
●
|
Cloth trim (Vacuum type) |
▲
|
2-point seat belt |
▲
|
Document box |
●
|
Heater |
N/A |
Operator presence switch |
▲
|
Standard connection widths |
328mm |
Optional connection widths |
320mm |
Testing |
EN13490 IT1
ISO 24135-1
ECE R16.08
ISO 3795 |
▲ : Option
● : Standard
N/A : Not Available
