MATERIAL HANDLING SEATS
21/MN60
Air suspension with 12V or 24V built-in compressor |
▲
|
Mechanical suspension |
●
|
Weight adjustment |
Manual up to 150kgs. |
Suspension stroke |
60mm |
Optional suspension stroke |
80mm |
Height adjustment |
N/A |
Turn Table |
▲
|
Slide travel |
210mm |
Lumbar adjustment |
N/A |
Hip restraints |
▲
|
Adjustable / Foldable armrests |
▲
|
Headrest |
▲ |
Backrest adjustment |
●
|
Vinyl trim (Vacuum type) |
●
|
Cloth trim (Vacuum type) |
▲
|
2-point seat belt |
▲ |
Document box-pouch |
▲
|
Heater |
▲
|
Operator presence switch |
▲
|
Standard connection width |
328mm |
Optional connection width |
320mm |
Testing |
EN13490 IT1,IT2
ECE R16.08
ISO 3795 |
▲ : Option
● : Standard
N/A : Not Available
