| Air suspension |
▲
|
| Air suspension with 12V or 24V built-in compressor |
▲
|
| Mechanical suspension |
●
|
| Weight adjustment |
Manual up to 150kgs. |
| Suspension stroke |
100mm |
| Optional suspension stroke |
60 mm - 80mm |
| Height adjustment |
60mm |
| Height adjustable pedestal with turn table |
▲
|
| Turn table |
▲ |
| Adjustable shock absorber |
N/A |
| Slide travel |
170mm |
| Lumbar adjustment |
▲
|
| Adjustable armrests |
▲ |
| Adjustable headrest |
● |
| Backrest adjustment |
● |
| Seat cushion tilt adjustment |
● |
| Seat cushion depth adjustment |
N/A |
| Vinyl trim |
●
|
| Cloth trim |
▲ |
| Genuine leather trim |
▲ |
| 3-point seat belt |
N/A |
| 2-point seat belt |
N/A |
| Document pouch |
▲
|
| Front Controls |
▲ |
| LH Controls |
● |
| RH Controls |
▲ |
| Footrest KIT |
▲ |
| Adjustable mounting rail |
▲ |
| Standard connection of seat |
216mm |
| Testing |
Materials flammability conforms
to IMO satndards |
