CONSTRUCTION SEATS
P215/CEA150D
Air suspension |
N/A |
Air suspension with 12V or 24V built-in compressor |
●
|
Mechanical suspension |
▲
|
Weight adjustment |
Automatic up to 150kgs. |
Suspension stroke |
140 mm |
Height adjustment |
80 mm |
Turn Table |
▲
|
Adjustable shock absorber |
▲
|
Slide travel |
190mm |
Lumbar adjustment |
▲
|
Horizontal isolator |
●
|
Adjustable / Foldable armrests |
▲ |
Adjustable headrest |
● |
Backrest adjustment |
● |
Seat cushion tilt adjustment |
● |
Seat cushion depth adjustment |
● |
Vinyl trim (Cut&Sew) |
▲ |
Cloth trim (Cut&Sew) |
● |
Vinyl trim (Vacuum type) |
N/A |
Cloth trim (Vacuum type) |
N/A |
3-point seat belt |
▲
|
2-point seat belt |
▲ |
Document box-pouch |
▲ |
Front Controls (except backrest recline handle) |
● |
LH Controls |
N/A |
RH Controls |
N/A |
Heater |
▲
|
Operator presence switch |
▲ |
Slides between seat top and suspension |
● |
Standard connection widths |
280mm |
Optional connection widths |
260mm (Order ----/EA150D) |
Testing |
ISO 6683
ISO 7096-EM3,4,6
ECE R16.08
ISO 3795 |
▲ : Option
● : Standard
N/A : Not Available
