AGRICULTURAL SEATS
P130/EA160DLF
Air suspension |
N/A |
Air suspension with 12V or 24V built-in compressor |
●
|
Mechanical suspension |
▲
|
Weight adjustment |
Automatic up to 150kgs. |
Suspension stroke |
100mm |
Height adjustment |
60mm |
Turn Table |
▲
|
Adjustable shock absorber |
▲
|
Slide travel |
190mm |
Lumbar adjustment |
▲
|
Horizontal isolator |
●
|
Adjustable / Foldable armrests |
▲
|
Adjustable headrest |
●
|
Backrest adjustment |
●
|
Seat cushion tilt adjustment |
N/A |
Seat cushion depth adjustment |
N/A |
Vinyl trim (Cut&Sew) |
▲ Order P135/EA160DLF |
Cloth trim (Cut&Sew) |
▲ Order P135/EA160DLF |
Vinyl trim (Vacuum type) |
●
|
Cloth trim (Vacuum type) |
▲ |
3-point seat belt |
N/A |
2-point seat belt |
▲
|
Document box-pouch |
▲ |
Heater |
▲ |
Operator presence switch |
▲ |
Slides between seat top and suspension |
● |
Standard connection widths |
260mm |
Optional connection widths |
280mm (Order ----/CEA160DLF) |
Testing |
EU 1322/2014 Annex XIV
Class I, II , III
ECE R16.08
ISO 3795
ISO 7096 EM3, EM5 |
▲ : Option
● : Standard
N/A : Not Available
